1、 SCOPE 適用范圍 The contents of specifications for TJC3 series connector strip， including product performance， test methods and inspection requirements 本規格書內容適用于 TJC3 系列條形連接器，包含了產品的性能、試驗方法和檢驗要求 2、 APPLICABLE STANDARDS 適用的標準 2.1 GB/T2421 Testing method for Environmental of Electrical Connectors Class 1： General Principles GB/T2421 電工電子產品環境試驗 第一部分 總則 2.2 GB/T2423 Testing method for Environmental of Electrical Connectors GB/T2423 電工電子產品環境試驗方法 2.3 GB/T2424 Testing method for Environmental of Electrical Connectors GB/T2424 電工電子產品環境試驗導則 2.4 GB/T5095 Testing Procedure/method for components of electric equipment 電子設備用機電元件基本試驗規程及測量方法 3、 USE CONDITION 使用條件 3.1 Ambient temperature Range：-25℃～+85℃ 環境溫度：-25℃～+85℃ 3.2 Applicable Wire Sizes:AWG#22～#28 適用線規：AWG#22～#28 3.3 Applicable PC board thickness:1.6mm 適用 PC 板厚度：1.6mm 4、 Appearance and Dimension 外觀及尺寸 4.1 Appearance:Product surface without defect、dirt、crack、and mechanical damang， Contact without rust，plating not oxided and not peeled. 產品表面不應有對制品有害的缺陷、污垢、裂痕及機械損傷；接觸件無銹蝕、鍍層氧化、脫落等現象。 4.2 Dimension:According to drawings 外形尺寸：依照附圖 4.3 Exchangable:Exchangable with same specification products. 互換性：相同規格應能互換
